Single Shaft Bubble Wrap Slitter Rewinder

Single shaft bubble wrap slitter rewinder is primarily designed for slitting bubble wrap and EPE foam. It features automatic edge guiding, automatic stopping based on measured length, and manual mechanical shaft loading.

Features:

1. Single shaft air expanding shaft for rewinding; rewinding tension is controlled via a magnetic powder system, while unwinding utilizes a mechanical brake.

2. Characterized by simple operation as well as stable and reliable performance.

Main Data:

Name:Single Shaft Bubble Wrap Slitter Rewinder

Model:PPD-BWS1500

Effective slitting width:100-1500 mm

Slitting thickness:0.5-5 mm

Speed:80–100 m/min

Unwinding diameter:max1200 mm

Unwinding magnetic powder brake:5 kg brake

Rewinding magnetic powder brakes:50 NM

Rewinding diameter:max600 mm

Power:4kw

Voltage:380V,50Hz
