Automatic Bandage Rolling Machine

Automatic bandage rolling machine is used to rewind small bandages from large gauze jumbo rolls,automatic stop when reach the setting length.
Machine can roll 3meter, 4meter, 5meter and also other special specification upon customers' requests.

Features:
1.Machine adopts PLC control, bandage length can be adjusted easily.
2.Automatic wrapping paper and gluing of banage roll.
3.Automatic counting,automatic rewind,take out bandage.
4.The max width of gauze bandage roll is 1250mm
5. The available gauze bandage diameter is max700mm

V8afIxSD46s

Main Data:

Name:Automatic Bandage Rolling Machine

Model:PPD-ABRM1250

Max raw material width:1250mm

Raw material diameter:max700mm

Product roll inner diameter:10mm

Speed:0-20m/min

Voltage:380V,50Hz

Power:4kw
