Single Tube End Chamfering Machine
CJ-60 Pneumatic Chamfering Machine
Experience the efficiency and precision of the CJ-60 chamfering machine, accommodating tube ends with an outer diameter (OD) of up to 60mm. This advanced chamfering solution is perfect for single tube end chamfering and is also compatible with solid bars.
Features:
Ensures Clean Surfaces for Tube Welding
Accurate Angular Chamfers for Enhanced Fitting & Assembly
Comprehensive I/O Chamfering & Facing Or Boring for Precision
Smooth Radius Chamfering for Improved Finishing
Precise Centering & Outer Chamfer and Drilling for Solid Bars"
Parameters:
Model | CJ-60 |
Type | Pneumatic /Hydraulic |
Pipe Diameter | 6-60mm |
Bar Diameter | 6-20mm |
Work Length | ≥35mm |
Work accuracy | ±0.1mm |
Work Speed | 3-5s/pcs |
Machine Motor | 1.0kw |
Work Pressure | MPA 6-8KG |
Weight | 200KG |
Dimension | 800*600*110cm |
Suit Material | Steel,Iron, Stainless Steel, Aluminum, Copper,Plastic,Nylon etc |
Shape Available | Round, Square, Hex, Bent Shape etc |
Workpiece Available | Pipe, Tube, Round Bar,Threaded Rod, Bolt, Nut etc |
