Oral Thin Film Making Machine

Oral thin film making machine is specialized in making liquid materials into thin film. It makes thin films by evenly spreading liquid materials on the bottom film.It can be used to make quick-dissolvable oral films, transfilms, and mouth freshener strips,with an extensive range of applications in medicine, cosmetics, health products and food industries.


Production process:
Put the solvent into the storage tank → transfer the solvent into the liquid tank → apply → dry and solidify → roll up

Features:
1.The whole power system adopts the AC variable frequency stepless speed regulation system composed of frequency converter.
2.The film roll winding adopts adaptive slip mode, the tension of large and small rolls is stable, and the operation is simple.
3.Independent oven (external heater, hot air circulation drying): segmented temperature control is adjustable.
4. Precision coating roller is used for coating and metering.

RtvERh3WAMM

Main Technical Data:

Name:Oral Thin Film Making Machine

Model:PPD-OTFM300

Coating width: Max 300mm

Coating thickness: 0.02-0.1mm

Coating speed: 0.01-1m/min

Bottom material width: 360mm, OD≤350mm, ID:76mm

Voltage: 380v 50Hz

Power:motor 1.5kw, heating 16kw

Air supply: 0.6-0.8Mpa

Machine weight: 1800KGS

Machine dimensions: 5300*1310*1750mm(L*W*H)
