CNC Medium Size End Milling Machine

CJ-200 CNC medium size end milling machine is for milling processing on the end faces of aluminum profiles, to ensure the fit between the mullion and the frame material.

1.Capable of milling multiple profiles at once, offering high efficiency.
2.Three-axis, two-part motors can simultaneously carry 4-6 pieces of tooling.
3.The tooling can be adjusted up and down, left and right, to accommodate different shapes and sizes of processing.
4.The tooling is adjustable, eliminating the need for custom tooling when machining different profiles, thus shortening production preparation, cycle time, and reducing costs.
5.The electrical system is equipped with a motor phase sequence protector, enhancing the system's safety.
6.The feed system uses a pneumatic-hydraulic damping device, ensuring stability and reliability.

Input power: 380V 50Hz

Total motor power: 4.4KW

Motor speed: 2800r/min

Air source working pressure: 0.5-0.8MPa

Milling cutter spindle diameter: φ250mm

Milling cutter diameter: φ250mm

Worktable feed stroke: 0-1360 mm

Workbench size: 330×320 mm

Motor adjustment stroke: 0-85 mm

Overall dimensions: 2240×1020×1670 mm
