BATTERY POWERED RIVETING TOOL
ED-50RIV
| Output: | 20~50kN |
| Stroke: | 35mm |
| Throat depth: | 35mm |
| Time/charger: | 200times |
| Time/cycle: | 3~8s |
| Voltage/capacity: | 18V/4.0Ah |
| N.weight (with battery): | 4.85kgs |
| Voltage of charger: | 100~240V AC |
| Charging time: | 80 mins |
| Accessories: | |
| Battery: | 2 pcs |
| Charger: | 1pc |
| Sealing ring of cylinder: | 1set |
| Sealing ring of safety valve: | 1set |
● The rivet force can be stepless adjustable according to the size of rivet and the strength of therivet material
● Sudden suspend function can be controlled at any time, even can retract manually.
● According to ergonomic design with antislip handle.
● Micro computer control system with the feature of self- pressure inspecting, double protection during operation, counting and realize the exchange between computer with data by the converter.
● High performance Li-ion battery to provide stronger power source, no discharge memory effects, one time charge 300 times can be effective for crimping.
